G1-24V-SW Standard Version NoDecal
- Item No.KMS05
- CategoryElectric Dirt Bikes
- Vehicle size1020*460*600MM
- Seat cushion height420MM
- Min. gruond clearance120MM-125MM
- Vehicle size730MM
- Max. Speed8km/h-12km/h-20km/h
- Range8-12KM
- Climbing degree≥35°
- Max. Loading capacity50KGS
G1-24V-SW Children's Electric Motorcycle — Standard Version (No Decal)
Item No.: KMS05 — supplied by Yongkang Komoshi Technology Co., Ltd.
The G1-24V-SW is a ride-on electric motorcycle designed for young riders. This Standard Version ships without decals, giving distributors and brand owners a clean body surface for their own graphics or private-label finishing. A brushless hub motor, three selectable speed levels and a 24V lead-acid battery form the core of the platform.
Key Features
- Three switchable speed levels: 8 km/h, 12 km/h and 20 km/h
- Brushless hub motor, rated 180 W with 450 W peak power
- 24V 4.5AH lead-acid battery, 108 WH capacity
- Climbing capability of 35° or more
- Maximum loading capacity of 50 KGS
- No-decal body, ready for custom graphics
Specifications
| Parameter | Value |
|---|---|
| Vehicle Size | 1020 × 460 × 600 MM |
| Vehicle Base | 730 MM |
| Seat Cushion Height | 420 MM |
| Min. Ground Clearance | 120 MM – 125 MM |
| Max. Speed | 8 km/h – 12 km/h – 20 km/h (switchable) |
| Range | 8 – 12 KM |
| Climbing Degree | ≥ 35° |
| Max. Loading Capacity | 50 KGS |
| Battery Type | 24V 4.5AH Lead-acid Battery |
| Battery Capacity | 108 WH |
| Battery Life Cycle | 500 cycles, remaining capacity ≥ 80% |
| Motor Type | Brushless Hub Motor |
| Rated Motor Power | 180 W |
| Maximum Power | 450 W |
| Controller | 24V – 45A |
| Charger & Time | 24V 1.5A CE Charger | 5h |
Standard Version vs. Premium Version
The platform is offered in two configurations. The table below lists the points where they differ; all other parameters are shared.
| Parameter | Premium Version (with decal) | Standard Version (no decal) |
|---|---|---|
| Range | 8 – 12 KM | 5 – 8 KM |
| Max. Loading Capacity | 50 KGS | 35 KGS |
| Battery Type | 24V 6AH Lead-acid Battery | 24V 4.5AH Lead-acid Battery |
| Battery Capacity | 144 WH | 108 WH |
Shared across both versions: vehicle size 1020 × 460 × 600 MM, vehicle base 730 MM, seat cushion height 420 MM, minimum ground clearance 120–125 MM, three switchable speed levels (8/12/20 km/h), climbing degree ≥ 35°, 500-cycle battery life with remaining capacity ≥ 80%, brushless hub motor, 180 W rated power, 450 W maximum power, 24V–45A controller, and a 24V 1.5A CE charger with a 5-hour charge time.
Applications
Suited to indoor and outdoor ride-on use for children, the G1-24V-SW is a fit for toy retailers, rental operators and brands seeking a no-decal base unit for their own artwork.
