LX-72-LY-22 Electric Off-Road Vehicle
Model LX-72-LY-22 (Item No. KMS04) is a high-performance electric off-road vehicle engineered for demanding terrain. With a mid-drive motor, high-capacity lithium battery, and robust construction, it delivers reliable power and control for recreational and utility applications.
Key Features
- Mid-drive motor with 2200 W rated power and 6500 W peak power
- 72V 25Ah ternary lithium battery (5C) with 1800 Wh capacity
- Range up to 60 km and top speed of 60–65 km/h
- Climbing capability of ≥ 65°
- Rated load 100 kg, maximum load 150 kg
- Road tires for versatile surface handling
Complete Technical Specifications
| Feature / Parameter | Specification Details |
|---|---|
| Tyre Configuration | Road Tires |
| Vehicle Size | 1840 × 685 × 1120 mm |
| Vehicle Base (Wheelbase) | 1150 mm |
| Seat Cushion Height | 860–870 mm |
| Min. Ground Clearance | 370 mm |
| Max. Speed | 60–65 km/h |
| Range | 60 km |
| Climbing Degree | ≥ 65° |
| Rated Loading Capacity | 100 kg |
| Max. Loading Capacity | 150 kg |
| Battery Type | 72V 25Ah domestic ternary lithium battery, 5C |
| Battery Capacity | 1800 Wh |
| Battery Life Cycle | 500 cycles (remaining capacity ≥ 80%) |
| Motor Type | Mid-drive Motor |
| Rated Motor Power | 2200 W |
| Maximum Power | 6500 W |
| Controller | 36–88V 80A |
| Charger | 5A Charger (CE certified) |
| Charger Time | 6 h |
Manufactured by Yongkang Komoshi Technology Co., Ltd., the LX-72-LY-22 combines power, range, and durability in a compact electric off-road platform. For further information, please contact the manufacturer.
